Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice Solenoid valves manifold Series 2200 "OPTYMA-S" 1 AIR DISTRIBUTION Series 2200 "OPTYMA-S" Optyma32-S is the 12.5 mm single-size version of the Optyma range, providing a nominal flow rate up to 500 Nl/min. It features a modular architecture with integrated electrical signal distribution, ensuring high flexibility, compact design,and easy configuration. Valve replacement can be carried out without disconnecting the pneumatic lines, greatly simplifying maintenance operations. - One size: 12,5 mm (same dimensions for monostable and bistable SV) - Flow rate: up to 550 Nl/min, using the modular base with Ø8 - Modular base with Ø4, Ø6, Ø8 quick fitting tube - The solenoid pilots are low consumption and fitted on the same side of the valve - Easy and fast assembly on the sub base thanks to the “one screw” mounting solution - Modular subbases assembled via tie rods - Electrical and pneumatic connections positioned on the same side - Possibility to operate with different pressures and vacuum - Management of 32 electrical signals,(16 bi-stable or any combination off mono and bi-stable vales up to max 32 signals) - The protection grade is IP65 directly integrated in the manifold components - The electrical connection is achieved thanks to a 37 pole connector - Possibility to integrate with Field Bus modules such as: CANopen , PROFIBUS DP, DeviceNet, EtherNet/IP, PROFINET IO RT, EtherCAT , IO-Link, CC-Link IE Field Basic ® ® Main characteristics Note: Shifting time of pneumatic directional control valves or moving parts, logic devices were measured in accordance to ISO 12238:2001, Pneumatic fluid power-Directional control valves-Measurement of shifting time Construction characteristics Body Technopolymer Operators Technopolymer Spacers NBR Spacer Technopolymer Spools AISI 303 stainless steel Springs AISI 303 stainless steel Pistons Technopolymer Piston seals NBR Functions SV 5/2 MONOSTABLE SOLENOID-SPRING SV 5/2 MONOSTABLE SOLENOID-DIFFERENTIAL SV 5/2 BISTABLE SOLENOID-SOLENOID SV 5/3 C.C. SOLENOID-SOLENOID SV 2x3/2 N.C.-N.C. (=5/3 O.C.) SOLENOID-SOLENOID SV 2x3/2 N.O.-N.O. (=5/3 P.C.) SOLENOID-SOLENOID SV 2x3/2 N.C.-N.O. SOLENOID-SOLENOID SV 2x3/2 N.O.-N.C. SOLENOID-SOLENOID Technical characteristics 24V ±10% 12V +10% - 0% Supply voltage DC AC DC NPN PNP / PNP Pilot consumption 1,3W nominal, in energy saving mode 0,6W nominal 1,3W nominal, in energy saving mode Pilot working pressure [12-14] from 2,5 to 7 bar max. Valve working pressure [1] from vacuum to 10 bar max. Operating temperature from -5°C to +50°C Protection degree IP65 Filtered air. No lubrication needed, if applied it shall be continuous 50000000 Life (standard operating conditions) Fluid 1
